Features

Available for rent or for sale

Chassis

• Freightliner M2
• 60,600 lbs. GVWR
• 14,600 lbs. front axle capacity
• 46,000 lbs. capacity rear axle, single speed, full floating
• Cummins ISC 8.3L engine, 300 HP
• Allison automatic transmission, overdrive 6-speed
• Engine-driven, water cooled, air compressor

Hub Drive

• Lift arm capacity:16,000 lbs. min.(32,000 lbs. on the deck)
• Reel size capacity (diameter): 5’ to 9’
• Reel size capacity (width): 40” to 72”
• Reel rotational power: 400,000 inch-lbs. @ 10 RPM min

Winch

• Bare drum rated capacity: 50,000 lbs
• ~875’ of 9/16” Dyform 6 wire rope
• Location: Bed mounted at front center of body at the bulkhead
• Sheave capacity: 30,000 lbs. min
